Planetary type Insulated Wire Stranding Machine
This planetary type stranding machine is mainly used for Stranding & Cabling Insulated Cores with 100% back-twist to make control cables, communication cables etc.
Planetary stranding machine is also widely used for stranding bare copper wire, aluminum wire with 100% back-twist to make copper strand, aluminum strand.
It can also be used for steel wire armoring or copper wire screening process.
With decades of manufacturing experience specialized in Planetary stranding machines, we have totally installed 850+ complete planetary stranding machines serving our valued wire and cable customers.
Features of our Planetary type Insulated Wire Stranding Machine
1. Planetary type stranding process with 100% back-twist to remove the wire internal stress.
2. Particularly suitable for insulated wire cores stranding and cabling process.
3. Wire pay-off tension from each bobbin is easily adjusted and uniform, the wire will not jump or bulge, which greatly improve the quality and efficiency of production.
4. Both ends of the Stranding cage have big bearing supported with a thick-walled seamless steel pipe.
5. Individual motor drive system, each stranding cage is driven by an individual ACVF motor.
6. Stranding pitch is continuously stepless adjustable.
7. SIEMENS PLC + SIEMENS HMI electrical control system, intelligent computing parameters.
8. Equipped with advanced wire-break detection system, which can detect the broken wire and display on HMI.
9. With decades of manufacture experience, all parts of the entire stranding system have been improved constantly.
10. German ZF brand Hysteresis tension system is optional, which can provide constant tension from bobbin full to empty. High accuracy, high stability.
| Single Wire diameter: | 1.0 – 4.5 mm | |
| Single Insulated Core diameter: | 1.5 – 8.0 mm | |
|
Cage & Bobbin Configurations: | Φ500/1+6 Φ500/6+12 Φ500/12+18 Φ500/6+12+18 Φ500/12+18+24 Φ500/6+12+18+24 | Φ630/1+6 Φ630/6+12 Φ630/12+18 Φ630/6+12+18 Φ630/12+18+24 Φ630/6+12+18+24 |
