Copper Tape Screening Machine
This Copper Taping machine is mainly used for copper tape screening on wires and cables.
The machine can be used as a taping head in other processing lines or in a separate copper tape screening line.
Menu
Features of our Copper Tape Screening Machine
1. Concentric type taping with individual motor drive.
2. Specially designed for Copper tapes or Copper-plastic tapes.
3. Copper tape pad diameter is 600 mm.
4. Taping head rotate speed is 600 rpm.
5. Stepless adjustable taping pitch.
6. PLC + HMI control system is available.
Main Technical Paramaters of Copper Taping Machine:
| Tape pad diameter | Φ500 | Φ600 | Φ700 |
| Tape width (mm) | 15~60 | 15~80 | 15~80 |
| Cable core OD (mm) | Φ80 | Φ100 | Φ120 |
| Max speed (rpm) | 700 | 600 | 500 |
